Fume DustKART 2
Fume DustKART 2
BY SPECIAL ORDER ONLY: these are ordered specially from our European supplier. Powerful mobile unit with compressed air filter cleaning system: 2.2kW motor. Designed to exhaust and filter dry airborne pollutants for continuous operation from welding, grinding, polishing, cutting of metals and plastics. Suitable for 2 arms
From $16487.00
The larger DustKART unit is designed for continuous operation and to handle bigger amounts of dust than a Fume Cube. It has a manual pulse cleaning system
• Dustkart is a mobile extraction unit with Compressed Air CLEANING
• G1 pre-filter, main filter and a G4 class outlet activated carbon filter
• 2000m3/h ie. 1000m3 at each hood (2x 160/3 OR 1 x 200/2 Fume Arms included in price)
• 2.2kW motor with Aluminium impellor
• Built-in manual ONE TOUCH compressed air cartridge cleaning system (requires compressed air supply line) 20litre compressed air tank
• 3 PHASE required- NEUTRAL AND EARTH SUPPLY
• Easy access Dust Drawers
• Designed for continuous operation where constant exhaust is required
- Can be hard wired or plug-in (3PH E+N Plugs NOT supplied with product)
| PRODUCT NAME | DustKART 2 |
| Manufactured | Europe |
| Power Requirement | 3x400V / 50Hz |
| Filter Area | 36 m2 |
| Noise Level dB (A) | 75 dB (A) |
| Filtration Efficiency % | 99% at 5um |
| Fan kW | 2.2 Aluminium impellor |
| Swivelling Arm | x 2 160 or 1 x 200 included in price |
| H x W x D mm | 1424 x 612 x 759 |
| Weight kg | 125 |
| Mobility/Castors | 2 lockable |
| Installation | Indoor only |
| Cable Length m | 4 |
| Casing Material | HEAVY DUTY Metal welded powder coated |
| DUST BIN Volume | 10 litre |
| Extraction Arm dia. | 2 x 160mm / 3m reach OR 1 x 200m/2-4m |
| Airflow m3/h | 2000 (1000m3/h at hood) |
| Filter 1 | Prefilter G2 Aluminium mesh |
| Filter 2 | 2 x Main Cartridge |
| Filter 3 | G4 Carbon activated |
| Plug included | NOT FITTED Requires 3 Ph E+N |
| Clean Air return to work area | Y |
|
Filter dirty warning Operation timer indicator |
Filter inducator |
|
Special feature |
Interchangeable inlet panels 160/200mm |
|
COMPRESSED AIR |
for manual cartridge cleaning system |
| Compressed Air Tank | 20 litre |
| Air Pressure | 5-5.5 Bar |
| Compressed Air connection | G1/2 |
Call 1800 370 846 for more information.
